Horizontal Shaft Concrete Mixer For Sale

Horizontal shaft concrete mixer sale also belongs to compulsory concrete mixer, there are mainly three types: JDC single shaft concrete mixer, JS series twin shaft concrete mixer and JSS double spiral belt concrete mixer. They all belong to multiple functional stirring machines, and they not only can stir concrete of fluidity, plastic, dry and hard, but also stir all kinds of mortar and light aggregate concrete. For JDC single shaft concrete mixer, it can be classified into two types: stationary and mobile. Stationary type is usually equipped with 1t motor roller, while mobile type is with tires, and it is more suitable for small and medium sized prefabricated components factory and sorts of construction sites, it is convenient to install and change the site. For JS and JSS series twin shaft concrete mixer, they can be used independently, and also can be equipped with PLD aggregate batching machine and used as the stirring engine in stationary concrete batching plant. They are well fit for industrial and civil construction projects like large and small prefabricated components factory, road, bridge, water conservancy, port, wharf, etc.
JDC350 single shaft concrete mixerJDC single shaft concrete mixer
1. Loading system is comprised of promotion mechanism, feeding hopper, feeding rack, feeding funnel and so on.
2. Stirring device is made up of stirring cylinder, stirring shaft, stirring blades and shaft-end seal device.
3. Stir rotation system includes motor, mixing gearbox, coupling and agitator shaft.
4. Water supply system consists of mini water pump, bottom valve, gate, water pipe, water spray pipe, etc.
5. Discharging system adopts new design of high-strength rack to form a rolling flip fast discharge structure.
6. The parts of rack are chassis, legs, walking wheel sets.
7. The electric control system includes the stirring motor, the lifting brake motor, the miniature pump motor, the turbine box discharge motor five trip switches and the control box, the control box is arranged on the operating side.

JS1000 twin shaft concrete mixerJS twin shaft concrete mixer and JSS series double spiral belt concrete mixer
1. Mixing system is made up of motor, pulley, reducer, open gear, mixing cylinder agitator and oil supply device, etc.
2. Feeding system is comprised of hoisting mechanism, feeding frame, hopper and feeding mouth.
3. Water supply system includes water pump, throttle valve, sprinkler and so on.
4. Discharging system is comprised of air pump, reversing valve, sub-valve, cylinder, etc. In addition, discharge manual operation lever is for temporary power failure when the emergency discharge and cylinder failure when the discharge, which usually should be removed to prevent wounding.
5. Electrical control circuit with air switch, fuse, thermal relay, with short circuit protection, overload protection function. All control buttons and air switch handles and indicators are arranged on the distribution box door, and a door lock. There is a protective cover on the outside of the button.
6. Electrical control circuit is set with air switch, fuse, thermal relay, with short circuit protection and overload protection function. All control buttons and air switch handles and indicators are arranged on the distribution box door, and there is a door lock. In addition, there is a protective cover on the outside of the button. Electrical components of distribution boxare installed in an insulation board, safe and reliable, operation and maintenance is easy and convenient.

Why choose horizontal concrete mixer?
1. Quality assurance. Adequate resources, production standards, product quality is guaranteed.
2. Convenient and practical. From the details, easy operation, high quality to provide quality experience.
3. Technology leader. We have a number of invention patents, business specifications, which will bring customers high quality experience.
4. Cost-effective. Technical selection, quality service and low-cost enjoyment.
5. Excellent service. To provide quality services, perfect after-sale protection.JSS double spiral belt concrete mixerSix performance characteristics
1. Wide application and reasonable price.
2. Low energy consumption and less noise.
3. Compact structure, easy operation and convenient maintenance.
4. Fast discharging speed, high production efficiency and good stirring quality.
5. Liner and stirring blades have long service life.

Ordering information
1. Learn about the technical performance and supporting range of the machine.
2. When the machine is shipped from the factory, the next track, ladder, bracing, connecting angle, legs, anchor bolts, suction pipe are in part state, the other components are in the whole assembly state.
3. The machine should choose more than or equal to 10t trucks to transport.
4. Hoisting should choose more than or equal to 25t tower crane.
5. The whole process of shipment should be safe and reliable, specific requirements are as follows:
6. In theprocess of loading,should pay attention to the center of gravity of the machine, which shall not be offset, hoisting wire rope should be accurately hung in the chassis round hook. (It is not permissible to lift the crane with the hook on the stirring cylinder.)
7. The machine and spare parts in the compartment should be firmly fixed, and hung with a safety hook.

Specifications

Model JDC350 JDC500 JDC1000
Charging Capacity (L) 560 800 1600
Discharging Capacity (L) 350 500 1000
Productivity (m3/h) 18 25 50
Aggregate Size (mm) 80/60 80/60 80/60
Rev of Drum (r/min) 28 24 24
Complete Machine Power (KW) 19.55 24.75 44
Mixing Time (s) 30 30 30
Overall Dimension (LXWXH) (mm) 2580X2340X2850 2600X2789X3200 3370X2789X3650
Dragged Speed (m/h) 20 18 18
Overall Weight (kg) 3300 4000 6100

Difference between traditional mixer and new mixer
1. Traditional concrete mixer, whether it is drum type or compulsory type can not work continuously, it should work with corresponding PLD concrete batching machine. While new concrete mixer integrates batching and mixing into a unit, which achieve continuous production, what’s more, new concrete mixer has simple and reasonable structure, it doesn’t need to install, which is very convenient.
2. Traditional concrete mixer technology is outdated, there is serious shortages in aspects of mixing time, raw materials and mixing quality. New type concrete mixer perfect the technology on the basis of traditional concrete mixer, which make up the malpractice of the traditional mixer and make the construction much more convenient.

About us
We Aimix not only have horizontal cement mixer, but also have vertical shaft concrete mixer, moreover, there are diesel concrete mixer, electric cement mixer, concrete pan mixer for sale, compulsory mixer, mobile concrete mixer, foam concrete mixer, concrete drum mixer, etc, among them, drum mixer can achieve high efficiency. If your project needs concrete with high quality, these three horizontal mixers will be your ideal choice, welcome to contact us and we will give you reasonable price.

Specifications

Item Charging Capacity (L) Discharging Capacity(L) Productivity( m³/h) Aggregate Size(cobble/gravel) (mm) Overall Dimension(LXWXH) (mm)
JS500 800 500 25 Min 80/60 4486x3030x5280
JS750 1200 750 35 Min 80/60 5100x2250x6700
JS1000 1600 1000 50 Min 80/60 8765x3436x9540
JS1500 2400 1500 75 Min 80/60 9645X3436X9700
JS2000 3200 2000 100 Min 80/60 3500X2320X1677
JS3000 4800 3000 150 Min 80/60 3990X2600X1700
JS4000 6400 4000 200 Min 120/100 4450X3050X2380
JSS500 800 500 20-25 Min 80/60 2960x2600x4400
JSS750 1200 750 30-35 Min 80/60 3120x3500x5620
JSS1000 1600 1000 40-50 Min 80/60 4640x2250x2250
JSS1500 2400 1500 70-90 Min 80/60 5058x2250x2440
JSS2000 3200 2000 100-120Min 80/60 3500x2400x2125
