AIMIX Ready Mix Concrete Pump

Ready Mix Concrete Pump

ready mix concrete pump
ready mix concrete pump

There are a lot of pumping problems in the operation and transportation process, so how to keep a good quality of concrete is an important thing. AIMIX ready mix concrete pump can make a good pumping process to avoid the ready mix concrete stick on the surface of the equipment. AIMIX ready mix concrete pump has the advantages of affordable price, large capacity, good quality, good performance, high efficiency and convenient operation as many concrete trailer pumps, so it is widely used in roads, tunnels, bridges, high-rise buildings, dams, water conservancy, hydropower and other construction projects. Pur main products are diesel ready mix concrete pump and electric ready mix concrete pump as follow.

Diesel ready mix concrete pump

HBTS50
HBTS50
Item: HBTS50-SR
Max. Theoretioal Throughput (m3/h): 50
Max. Pumping Pressure(MPa): 13
Max. Theoretical Vertical Conveying Distance(m): 180
Max. Theoretioal Horizontal Conveying Distance: 600
Max. Aggregate Diameter(mm): 40/50
Conveying Cylinder Bore X Piston Stroke(mm): Φ180×1300
Diesel Brand: DELIER/DEUTZ
Power of Diesel Motor(kw): 62

HBTS60
HBTS60
Item: HBTS60-SR
Max. Theoretioal Throughput: (m3/h) 60
Max. Pumping Pressure(MPa): 13/15/16
Max. Theoretical Vertical Conveying Distance(m): 190
Max. Theoretioal Horizontal Conveying Distance: 800
Max. Aggregate Diameter(mm): 50
Conveying Pipe Radius(mm): 150
Diesel Brand: DEUTZ
Power of Diesel Motor(kw): 82/129

HBTS80
HBTS80
Item: HBTS80-SR
Max. Theoretioal Throughput: (m3/h) 80
Max. Pumping Pressure(MPa): 16
Max. Theoretical Vertical Conveying Distance(m): 200
Max. Theoretioal Horizontal Conveying Distance: 1000
Max. Aggregate Diameter(mm): 50
Conveying Pipe Radius(mm): 150
Hydraulic Oil Tank Capacity(L): 580
Diesel Brand: DEUTZ
Power of Diesel Motor(kw): 162

Specifications of diesel type ready mix concrete pump:

Item XHBT-25SR XHBT-30SR HBTS40-SR HBTS50-SR
Max. Theoretioal Throughput (m3/h) 25 30 40 50
Max. Pumping Pressure(MPa) 10 10 11/13/15 13
Max. Theoretical Vertical Conveying Distance(m) 150 150 150 180
Max. Theoretioal Horizontal Conveying Distance 600 600 600 600
Max. Aggregate Diameter(mm) 20 20/30 30/40 40/50
Slump(cm) 12—23 12—23 12—23 12—23
Conveying Pipe Radius(mm) 100 100 125 125/150
Conveying Cylinder Bore X Piston Stroke(mm) Φ140×1000 Φ140×1100 Φ180×1300 Φ180×1300
Hydraulic Oil Tank Capacity(L) 240 370 370 370
Feeding Height(mm) 1100 1100 1250 1300
Hopper Capacity(m³) 0.35 0.4 0.6 0.68
Diesel Brand Delier Delier DELIER/DEUTZ DELIER/DEUTZ
Power of Diesel Motor(kw) 46 49 56 62
Dimension(Length*Width*Weight)(mm) 4500*1750*1600 4800*1750*1600 5000*1850*1700 5000*2100*2260
Total Weight(kg) 3500 3750 4500 4500
Item HBTS60-SR HBTS80-SR HBTS90-SR
Max. Theoretioal Throughput (m3/h) 60 80 90
Max. Pumping Pressure(MPa) 13/15/16 16 16/18
Max. Theoretical Vertical Conveying Distance(m) 190 200 200
Max. Theoretioal Horizontal Conveying Distance 800 1000 1200
Max. Aggregate Diameter(mm) 50 50 50
Slump(cm) 12—23 12—23 12—23
Conveying Pipe Radius(mm) 150 150 150
Conveying Cylinder Bore X Piston Stroke(mm) Φ200×1650 Φ200×1800 Φ200×1800
Hydraulic Oil Tank Capacity(L) 580 580 580
Feeding Height(mm) 1400 1420 1420
Hopper Capacity(m³) 0.68 0.68 0.8
Diesel Brand DEUTZ DEUTZ DEUTZ
Power of Diesel Motor(kw) 82/129 162 176
Dimension(Length*Width*Weight)(mm) 6000*2160*2600 6700*2160*2700 6750*2160*2700
Total Weight(kg) 6480 7600 7600

Electric ready mix concrete pump

BS30D
BS30D
Item: HBT-20
Max. Theoretical  Throughput(m3/h): 20
Max. Pumping Pressure(MPa): 10
Max.Vertical Conveying Distance(m): 140
Max.Horizontal Conveying Distance(m): 500
Max. Aggregate Diameter(mm): 20
Conveying Pipe Radius(mm): 100
Hydraulic Oil Tank Capacity(L): 240
Feeding Height(mm): 1100
Hopper Capacity(m3): 0.35
Power(kw): 37


BS30D
BS30D
Item: HBT-30
Max. Theoretical  Throughput(m3/h): 30
Max. Pumping Pressure(MPa): 11
Max.Vertical Conveying Distance(m): 150
Max.Horizontal Conveying Distance(m): 600
Max. Aggregate Diameter(mm): 20/30
Conveying Pipe Radius(mm): 100
Hydraulic Oil Tank Capacity(L): 370
Feeding Height(mm): 1100
Hopper Capacity(m3): 0.4
Power(kw): 45


BS40D
BS40D
Item: HBT-40
Max. Theoretical  Throughput(m3/h): 40
Max. Pumping Pressure(MPa): 11 or 13
Max.Vertical Conveying Distance(m): 150
Max.Horizontal Conveying Distance(m): 600
Max. Aggregate Diameter(mm): 30/40
Conveying Pipe Radius(mm): 125
Hydraulic Oil Tank Capacity(L): 370
Feeding Height(mm): 1100
Hopper Capacity(m3): 0.6
Power(kw): 45/56

Specifications of electric type ready mix concrete pump:

Item HBT-20 HBT-30 HBT-40 HBT-50
Max. Theoretical  Throughput(m3/h) 20 30 40 50
Max. Pumping Pressure(MPa) 10 11 11/13 12/13
Max.Vertical Conveying Distance(m) 140 150 150 150
Max.Horizontal Conveying Distance(m) 500 600 600 600
Max. Aggregate Diameter(mm) 20 20/30 30/40 40/50
Conveying Pipe Radius(mm) 100 100 125 125/150
Conveying Cylinder Bore X Piston Stroke(mm) Φ140×1000 Φ160×1200 Φ180×1200 Φ180×1300
Hydraulic Oil Tank Capacity(L) 240 370 370 370
Feeding Height(mm) 1100 1100 1100 1400
Hopper Capacity(m3) 0.35 0.4 0.6 0.68
Power(kw) 37 45 45/56 75
Dimension(Length×Width×Height)(mm) 4000×1350×1550 4500×1750×1600 4600×1850×1770 5200×2000×2260
Item HBT-60 HBT-80 HBT-90
Max. Theoretical  Throughput(m3/h) 60 80 90
Max. Pumping Pressure(MPa) 13/15/16 16 16/18
Max.Theoretical Vertical Conveying Distance(m) 190 200 220
Max.Theoretical Horizontal Conveying Distance(m) 800 1000 1200
Max. Aggregate Diameter(mm) 50 50 50
Conveying Pipe Radius(mm) 150 150 150
Conveying Cylinder Bore X Piston Stroke(mm) Φ200×1650 Φ200×1800 Φ200×1850
Hydraulic Oil Tank Capacity(L) 580 580 580
Feeding Height(mm) 1420 1420 1420
Hopper Capacity(m3) 0.68 0.68 0.8
Power(kw) 90 110 110
Dimension(Length×Width×Height)(mm) 6000×2160×2600 6300×2100×2250 6300×2100×2250

Features and Advantages of AIMIX Ready Mix Concrete Pump:

Our machine has a large capacity, which can mix more concrete in a short time.

Our machine can ensure a good quality of concrete to avoid concrete stick on the surface of it.

Our machine can shorten your construction time and improve your construction efficiency.

Our machine is equipped with PLC and remote control, which is really convenient to operate for users.

Our machine has a reliable performance and affordable price than concrete pump small, which is really worth buying.

Company Information

A good ready mix concrete pump can bring more value right away, and we AIMIX will give you a good price that you can afford. AIMIX is the leading enterprise of china construction equipment, which has got the certification of CE and ISO9001:2000. As a verified supplier bu BV and Alibaba, our products has been delivered to more than 70 countries in the world now. Our equipment are twin shaft concrete mixer, stationary concrete batching plant, diesel concrete pump, cement mortar pump, stabilized soil plant, asphalt mixing plant, dry mortar plant, tower crane, block making machine, construction lift, wheel loader, concrete mixer truck, concrete boom pump, self loading concrete mixer truck, diesel generator, rebar bending and cutting machine and other products.

Please feel free to give your inquiry in the form below. We will reply in 24 hours.
