AIMIX aims to promote the industrial development of Australia, so we provide customers with the different types of concrete pumps for sale Australia, they are used to pump concrete for special zone economy, transportation, railway, water conservancy, electric power project, and national defense construction.
The main types are concrete trailer pumps for sale, and concrete mixers and pumps, which are mainly 40m3/h to 100m3/h as theoretical output, can convey concrete conveniently. What’s more, for areas that lack electricity, we can supply you with concrete pumps Australia with diesel engines.
If you click to consult and place an order now, there will be exquisite accessories delivered.
How To Choose Right Concrete Line Pump For Sale Australia
A. See materials of machine itself.
Materials of concrete pumps for sale in Australia relate to its service life and whether users can earn money from it. we AIMIX GROUP have noticed this point for years, we found that bad steel materials will shorten the usage time of the machine, therefore, we stick to use wear-resistant steel materials, let our concrete pumps for sale Australia can make the best of them.
Specifications Of Diesel Concrete Line Pump
| Items | Units | ABT25C | ABT30C | ABT40C | ABT60C | ABT80C |
| Max. theo. concrete output(L./H) | M3/h | 25 | 30 | 40/26 | 67/45 | 84/45 |
| Max.concrete pumping pressure(H./L.) | MPa | 8 | 10 | 10/7.6 | 43659 | 43785 |
| Distribution valve type | SÂ Valve | SÂ Valve | SÂ Valve | SÂ Valve | SÂ Valve | |
| Concrete cylinder diameter×stroke | mm | Φ140×845 | Φ140×1200 | Φ180×1200 | Φ200×1650 | Φ200×1800 |
| Hopper capacity x feeding height | L/mm | 400/1100 | 400/1100 | 400/1100 | 800/1400 | 800/1400 |
| Outlet diameter | mm | Φ100 | Φ100 | Φ150 | Φ180 | Φ180 |
| Diesel engine model | Weifang Delier 4100 | Weifang Delier 4100 | Weifang Delier 6105ZB | Wechai | Wechai | |
| Electrical engineering power | KW | 56 | 56 | 82 | 129 | 176 |
| Rotate speed | r/min | 1800 | 1800 | 2100 | 2200 | 2200 |
| Circuit type | Open circuit | |||||
| Pumping system pressure | MPa | 18 | 26 | 32 | 32 | 32 |
| Mixing system pressure | MPa | 43624 | 43624 | 43624 | 43624 | 43624 |
| Capacity of oil tank | L | 260 | 260 | 370 | 370 | 580 |
| Max. Theoretical Vertical/Horizontal Conveying Distance | m | 120/300 | 120/300 | 120/500 | 180/800 | 200/800 |
| Max. aggregate diameter | mm | Slick/scree:10/20 | Slick/scree:10/20 | Slick/scree:40/50 | Slick/scree:40/50 | Slick/scree:40/50 |
| Inside diameter of delivering pipe | mm | Φ100 | Φ100 | Φ125 | Φ125 | Φ125 |
| Dimensions：length×width×height | mm | 4500x1750x1600 | 4500x1750x1600 | 5000x1850x1700 | 5800x2000x1750 | 6300x2100x2350 |
| Total weight | kg | 3000 | 3500 | 4500 | 6500 | 6900 |
B. Pay much more attention to after-sales service.
Users who bought line pumps for sale Australia, must want to use them for a long time, thus, users should notice the after-sales service, when you choose manufacturer, you must do a survey about their after-sales, otherwise, once your concrete pump truck for sale Australia goes wrong, you can’t get a reply from concrete pump manufacturers Australia. We Aimix Group attaches importance to after-sales service, even pre-sales, and on-sales service, we aim to build long-term business relationships with our users, so we have established professional after-sales service groups, they will solve your problems at any time.
After-Sales Guarantee From AIMIX GROUP-Pump Manufacturer In Australia
1. Provide users with professional technical consulting service and construction scheme for concrete pumps Australia for sale.
2. Provide users with professional technical training workers.
3. On-site installation and debug.
4. Free operational guidance and follow-up service for half a month.
5. Provide users with regular maintenance guidance and quality maintenance service.
6. Establish a perfect after-sales service tracking system, do regular checks for your concrete pump in Australia.
7. Permanent 24-hour after-sales service.
| Items | Units | ABT25D | ABT30D | ABT40D | ABT60D | ABT80D |
| Max. theo. concrete output(L./H) | M3/h | 25 | 30 | 40 | 60/36 | 86/45 |
| Max.concrete pumping pressure(H./L.) | MPa | 10 | 10 | 10 | 13/7 | 16/11 |
| Distribution valve type | S Valve | S Valve | S Valve | S Valve | S Valve | |
| Concrete cylinder diameter×stroke | mm | Φ140×845 | Φ140×845 | Φ180×1200 | Φ200×1650 | Φ200×1800 |
| Hopper capacity x feeding height | L/mm | 400/1100 | 400/1100 | 400/1100 | 800/1100 | 800/1100 |
| Outlet diameter | mm | Φ100 | Φ100 | Φ100 | Φ180 | Φ180 |
| Electrical engineering power | KW | 37 | 18 | 45 | 90 | 90 |
| Rotate speed | r/min | 1480 | 1480 | 1480 | 1480 | 1480 |
| Circuit type | Open circuit | |||||
| Pumping system pressure | MPa | 18 | 18 | 28 | 28 | 32 |
| Mixing system pressure | MPa | 6-8 | 6-8 | 8 | 6-8 | 14 |
| Capacity of oil tank | L | 260 | 260 | 370 | 560 | 580 |
| Max. Theoretical Vertical/Horizontal Conveying Distance | m | 100/400 | 120/500 | 120/500 | 160/800 | 200/800 |
| Max. aggregate diameter | mm | Slick/scree:10/20 | Slick/scree:10/20 | Slick/scree:40/50 | Slick/scree:40/50 | Slick/scree:40/50 |
| Inside diameter of delivering pipe | mm | Φ80 | Φ80 | Φ125 | Φ125 | Φ125 |
| Dimensions：length×width×height | mm | 3400x1420x1600 | 4500x1750x1600 | 4500x1750x1600 | 4500x1750x1600 | 6300x2100x2250 |
| Total weight | kg | 2300 | 2300 | 3200 | 6000 | 6300 |
C. Notice concrete pump cost Australia.
When referring to price of concrete pumps sales Australia, you can’t only see the price, if you want to finish your project smoothly and successfully, you need to notice the quality; whether the concrete pump for sale Australia is suitable for your project; product service. Only take these three points into consideration, you can get the best concrete pumping equipment in Australia.
Our Strength For Concrete Line Pumps For Sale In Australia
1. Main oil pump adopt brand variable piston pump, high rated voltage; adopt valve box from EATON.
2. We use an electronically controlled hydraulic system, low failure rate, and easy maintenance.
3. Double cooling system, ensure trailer mounted concrete pump for sale Australia can work normally in such hot weather.
Concrete Boom Pumps For Sale Australia
Specifications Of Concrete Boom Pump For Sale Australia
| Item | Unit | KNL5206THB 30-4M | KNL5231THB 37-5RZ | KNL5340THB 44-5RZ |
| Max. Theor. output(high/low pressure) | m3/h | 66/111 | 66/111 | 75/125 |
| Max. Theor. concrete output Pressure(high/low pressure) | MPa | 10/6 | 10/6 | 10/6 |
| Rated working pressure | MPa | 32 | 32 | 32 |
| Pumping frequency(high/low pressure) | min-1 | 18/30 | 19/32 | 15/25 |
| Hopper capacity | L | 600 | 600 | 600 |
| Filling height | mm | 1200 | 1200 | 1400 |
| Hydraulic system type | Open loop | Open loop | Open loop | |
| Distribution valve | S valve | S valve | S valve | |
| Oil cylinder dia.×stroke | mm | φ125×1400/1400 | φ125×1400 | φ140×1800 |
| Concrete cylinder dia.×stroke | mm | φ230×1400/1400 | φ230×1400 | φ260×1800 |
| Hydraulic oil cooling | Air cooling | Air cooling | Air cooling | |
| Recommended concrete slump | cm | 12~23 | 12~23 | 12~23 |
| Max. aggregate dimension | mm | 40 | 40 | 40 |
| Structure type | 30-4M | 37-5RZ | 44-5RZ | |
| Placing depth | m | 30 | 36.1 | 43.5 |
| Horizontal distance | m | 26 | 32.6 | 40 |
| Placing depth | m | 22 | 25.5 | 29.5 |
| Slewing angle | ±270° | ±270° | 540° | |
| Pipe diameter | mm | 125 | 125 | 125 |
| End hose length | mm | 3000 | 3000 | 3000 |
| Chassis model | mm | EQ5200GSZ5DJ | ZZ5231N521GE1 | ZZ5347V524HE1 |
| Wheelbase | 5200 | 5200 | 4800+1400 | |
| Engine type | mm | YC6A270-50 | MC07.31-50 | MC11.40-50 |
| Engine power | 199kw | 228kw | 297kw | |
| Oil tank cubage | kW | 400 | 400 | 400 |
| Overall dimensions | 10300x2350x3660 | 9840x2496x3870 | 11905x2500x3910 | |
| Oil tank volume | 500 | 500 | 600 | |
| Control mode | L | Manual＋remote control | Manual＋remote control | Manual＋remote control |
| Maximum water pressure | 0.8 | 0.8 | 7 | |
| Pipe cleaning mode | L | Water cleaning/dry cleaning | Water cleaning/dry cleaning | Water cleaning/dry cleaning |
| Item | Unit | KNL5340THB 47-6RZ | KNL5350THB 50-6RZ | KNL5420THB 58X-6RZ |
| Max. Theor. output(high/low pressure) | m3/h | 75/125 | 75/125 | 108/183 |
| Max. Theor. concrete output Pressure(high/low pressure) | MPa | 10/6 | 10/6 | 10/6 |
| Rated working pressure | MPa | 32 | 32 | 34 |
| Pumping frequency(high/low pressure) | min-1 | 15/25 | 15/25 | 16/28 |
| Hopper capacity | L | 600 | 600 | 600 |
| Filling height | mm | 1400 | 1400 | 1400 |
| Hydraulic system type | Open loop | Open loop | Open loop | |
| Distribution valve | S valve | S valve | S valve | |
| Oil cylinder dia.×stroke | mm | φ140×1800 | φ140×1800 | φ140×2100 |
| Concrete cylinder dia.×stroke | mm | φ260×1800 | φ260×1800 | φ260×2100 |
| Hydraulic oil cooling | Air cooling | Air cooling | Air cooling | |
| Recommended concrete slump | cm | 12~23 | 12~23 | 12~23 |
| Max. aggregate dimension | mm | 40 | 40 | 40 |
| Structure type | 47-6RZ | 50-6RZ | 58-6RZ | |
| Placing depth | m | 46.8 | 49.2 | 58 |
| Horizontal distance | m | 42.6 | 45.3 | 54 |
| Placing depth | m | 32.5 | 35.3 | 41.2 |
| Slewing angle | 540° | 540° | ±270° | |
| Pipe diameter | mm | 125 | 125 | 125 |
| End hose length | mm | 3000 | 3000 | 3000 |
| Chassis model | mm | ZZ5347V524HE1 | ZZ5356V524ME1 | QL5420THBW2TDHY |
| Wheelbase | 4800+1400 | 4650+1400 | 1850+4575+1370 | |
| Engine type | mm | MC11.40-50 | MC11.40-50 | 6WG1-TCG51 |
| Engine power | 297kw | 297kw | 338kw | |
| Oil tank cubage | kW | 400 | 400 | 400 |
| Overall dimensions | 12295x2550x4000 | 12230x2550x4000 | 14040x2500x4000 | |
| Oil tank volume | 600 | 600 | 800 | |
| Control mode | L | Manual＋remote control | Manual＋remote control | Manual＋remote control |
| Maximum water pressure | 7 | 7 | 0.8 | |
| Pipe cleaning mode | L | Water cleaning/dry cleaning | Water cleaning/dry cleaning | Water cleaning/dry cleaning |
We can also supply users all types of boom pumps for sale Australia, which are suitable for high building construction. We have 24m, 25m, 37m, 42m and 48m for your selection.
In addition concrete pump truck Australia, concrete line pumps for sale Australia, trailer concrete pumps for sale Australia, we also have concrete mixer with pump,mini concrete pumps for sale Australia for your choice, anyway, we will try our best to meet your demands. Last but not least, why you will get best price for line concrete pumps for sale Australia? Because we are going to establish oversea office in Australia, in addition, we have established oversea office in Uzbekistan, Pakistan, Philippines and Sri Lanka, etc, it is will be more and more convenient for you to buy from us!
Other Hot Sale Products
Items: ABJZ40C
Max. theo. concrete output(L./H)(M3/h): 40
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.45
Max.concrete pumping pressure(H./L.)(MPa): 10
Distribution valve type: S Valve
Winding motor power(KW): Hydraulic motor
Stir the motor power(KW): Hydraulic motor
Water pump motor power(KW): Hydraulic motor
Items: ABJZ30C
Max. theo. concrete output(L./H)(M3/h): 30
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.35
Max.concrete pumping pressure(H./L.)(MPa): 10
Distribution valve type: S Valve
Winding motor power(KW): Hydraulic motor
Stir the motor power(KW): Hydraulic motor
Water pump motor power(KW): Hydraulic motor
Items: ABJS40D
Max. theo. concrete output(L./H)(M3/h): 40
Concrete mixer model: JS750
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.75
Max.concrete pumping pressure(H./L.)(MPa): 8
Distribution valve type: S Valve
Winding motor power(KW): 7.5
Stir the motor power(KW): 30
Water pump motor power(KW): 0.75
Items: ABJZ30D
Max. theo. concrete output(L./H)(M3/h): 30
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.35
Max.concrete pumping pressure(H./L.)(MPa): 10
Distribution valve type: S Valve
Winding motor power(KW): 5.5
Stir the motor power(KW): 4.5
Water pump motor power(KW): 0.55
