Concrete Pumps For Sale Australia

AIMIX aims to promote the industrial development of Australia, so we provide customers with the different types of concrete pumps for sale Australia, they are used to pump concrete for special zone economy, transportation, railway, water conservancy, electric power project, and national defense construction.

concrete trailer pump in Indonesia

The main types are concrete trailer pumps for sale, and concrete mixers and pumps, which are mainly 40m3/h to 100m3/h as theoretical output, can convey concrete conveniently. What’s more, for areas that lack electricity, we can supply you with concrete pumps Australia with diesel engines.

If you click to consult and place an order now, there will be exquisite accessories delivered.

How To Choose Right Concrete Line Pump For Sale Australia

A. See materials of machine itself.

Materials of concrete pumps for sale in Australia relate to its service life and whether users can earn money from it. we AIMIX GROUP have noticed this point for years, we found that bad steel materials will shorten the usage time of the machine, therefore, we stick to use wear-resistant steel materials, let our concrete pumps for sale Australia can make the best of them.

ABT40C concrete line pump for sale australia
ABT40C concrete line pump for sale australia


ABT60C concrete pump with diesel engine
ABT60C concrete pump with diesel engine


ABT80C diesel concrete line pump
ABT80C diesel concrete line pump


Specifications Of Diesel Concrete Line Pump

ItemsUnitsABT25CABT30CABT40CABT60CABT80C
Max. theo. concrete output(L./H)M3/h253040/2667/4584/45
Max.concrete pumping pressure(H./L.)MPa81010/7.64365943785
Distribution valve typeS ValveS ValveS ValveS ValveS Valve
Concrete cylinder diameter×strokemmΦ140×845Φ140×1200Φ180×1200Φ200×1650Φ200×1800
Hopper capacity x feeding heightL/mm400/1100400/1100400/1100800/1400800/1400
Outlet diametermmΦ100Φ100Φ150Φ180Φ180
Diesel engine modelWeifang Delier 4100Weifang Delier 4100Weifang Delier 6105ZBWechaiWechai
Electrical engineering powerKW565682129176
Rotate speedr/min18001800210022002200
Circuit typeOpen circuit
Pumping system pressureMPa1826323232
Mixing system pressureMPa4362443624436244362443624
Capacity of oil tankL260260370370580
Max. Theoretical Vertical/Horizontal Conveying Distancem120/300120/300120/500180/800200/800
Max. aggregate diametermmSlick/scree:10/20Slick/scree:10/20Slick/scree:40/50Slick/scree:40/50Slick/scree:40/50
Inside diameter of delivering pipemmΦ100Φ100Φ125Φ125Φ125
Dimensions:length×width×heightmm4500x1750x16004500x1750x16005000x1850x17005800x2000x17506300x2100x2350
Total weightkg30003500450065006900

B. Pay much more attention to after-sales service.

Users who bought line pumps for sale Australia, must want to use them for a long time, thus, users should notice the after-sales service, when you choose manufacturer, you must do a survey about their after-sales, otherwise, once your concrete pump truck for sale Australia goes wrong, you can’t get a reply from concrete pump manufacturers Australia. We Aimix Group attaches importance to after-sales service, even pre-sales, and on-sales service, we aim to build long-term business relationships with our users, so we have established professional after-sales service groups, they will solve your problems at any time.

After-Sales Guarantee From AIMIX GROUP-Pump Manufacturer In Australia

1. Provide users with professional technical consulting service and construction scheme for concrete pumps Australia for sale.

2. Provide users with professional technical training workers.

3. On-site installation and debug.

4. Free operational guidance and follow-up service for half a month.

5. Provide users with regular maintenance guidance and quality maintenance service.

6. Establish a perfect after-sales service tracking system, do regular checks for your concrete pump in Australia.

7. Permanent 24-hour after-sales service.

ABT40D electric concrete line pump
ABT40D electric concrete line pump


ABT60D electric concrete pump
ABT60D electric concrete pump


ABT80D electric concrete line pump australia
ABT80D electric concrete line pump australia


ItemsUnitsABT25DABT30DABT40DABT60DABT80D
Max. theo. concrete output(L./H)M3/h25304060/3686/45
Max.concrete pumping pressure(H./L.)MPa10101013/716/11
Distribution valve typeS ValveS ValveS ValveS ValveS Valve
Concrete cylinder diameter×strokemmΦ140×845Φ140×845Φ180×1200Φ200×1650Φ200×1800
Hopper capacity x feeding heightL/mm400/1100400/1100400/1100800/1100800/1100
Outlet diametermmΦ100Φ100Φ100Φ180Φ180
Electrical engineering powerKW3718459090
Rotate speedr/min14801480148014801480
Circuit typeOpen circuit
Pumping system pressureMPa1818282832
Mixing system pressureMPa6-86-886-814
Capacity of oil tankL260260370560580
Max. Theoretical Vertical/Horizontal Conveying Distancem100/400120/500120/500160/800200/800
Max. aggregate diametermmSlick/scree:10/20Slick/scree:10/20Slick/scree:40/50Slick/scree:40/50Slick/scree:40/50
Inside diameter of delivering pipemmΦ80Φ80Φ125Φ125Φ125
Dimensions:length×width×heightmm3400x1420x16004500x1750x16004500x1750x16004500x1750x16006300x2100x2250
Total weightkg23002300320060006300

C. Notice concrete pump cost Australia.

When referring to price of concrete pumps sales Australia, you can’t only see the price, if you want to finish your project smoothly and successfully, you need to notice the quality; whether the concrete pump for sale Australia is suitable for your project; product service. Only take these three points into consideration, you can get the best concrete pumping equipment in Australia.

Our Strength For Concrete Line Pumps For Sale In Australia

1. Main oil pump adopt brand variable piston pump, high rated voltage; adopt valve box from EATON.

2. We use an electronically controlled hydraulic system, low failure rate, and easy maintenance.

3. Double cooling system, ensure trailer mounted concrete pump for sale Australia can work normally in such hot weather.

Concrete Boom Pumps For Sale Australia

25m concrete boom pump
25m concrete boom pump


37m concrete boom truck
37m concrete boom truck


38m boom pump truck
38m boom pump truck


Specifications Of Concrete Boom Pump For Sale Australia

ItemUnitKNL5206THB 30-4MKNL5231THB 37-5RZKNL5340THB 44-5RZ
Max. Theor. output(high/low pressure)m3/h66/11166/11175/125
Max. Theor. concrete output Pressure(high/low pressure)MPa10/610/610/6
Rated working pressureMPa323232
Pumping frequency(high/low pressure)min-118/3019/3215/25
Hopper capacityL600600600
Filling heightmm120012001400
Hydraulic system typeOpen loopOpen loopOpen loop
Distribution valveS valveS valveS valve
Oil cylinder dia.×strokemmφ125×1400/1400φ125×1400φ140×1800
Concrete cylinder dia.×strokemmφ230×1400/1400φ230×1400φ260×1800
Hydraulic oil coolingAir coolingAir coolingAir cooling
Recommended concrete slumpcm12~2312~2312~23
Max. aggregate dimensionmm404040
Structure type30-4M37-5RZ44-5RZ
Placing depthm3036.143.5
Horizontal distancem2632.640
Placing depthm2225.529.5
Slewing angle±270°±270°540°
Pipe diametermm125125125
End hose lengthmm300030003000
Chassis modelmmEQ5200GSZ5DJZZ5231N521GE1ZZ5347V524HE1
Wheelbase520052004800+1400
Engine typemmYC6A270-50MC07.31-50MC11.40-50
Engine power199kw228kw297kw
Oil tank cubagekW400400400
Overall dimensions10300x2350x36609840x2496x387011905x2500x3910
Oil tank volume500500600
Control modeLManual+remote controlManual+remote controlManual+remote control
Maximum water pressure0.80.87
Pipe cleaning modeLWater cleaning/dry cleaningWater cleaning/dry cleaningWater cleaning/dry cleaning
ItemUnitKNL5340THB 47-6RZKNL5350THB 50-6RZKNL5420THB 58X-6RZ
Max. Theor. output(high/low pressure)m3/h75/12575/125108/183
Max. Theor. concrete output Pressure(high/low pressure)MPa10/610/610/6
Rated working pressureMPa323234
Pumping frequency(high/low pressure)min-115/2515/2516/28
Hopper capacityL600600600
Filling heightmm140014001400
Hydraulic system typeOpen loopOpen loopOpen loop
Distribution valveS valveS valveS valve
Oil cylinder dia.×strokemmφ140×1800φ140×1800φ140×2100
Concrete cylinder dia.×strokemmφ260×1800φ260×1800φ260×2100
Hydraulic oil coolingAir coolingAir coolingAir cooling
Recommended concrete slumpcm12~2312~2312~23
Max. aggregate dimensionmm404040
Structure type47-6RZ50-6RZ58-6RZ
Placing depthm46.849.258
Horizontal distancem42.645.354
Placing depthm32.535.341.2
Slewing angle540°540°±270°
Pipe diametermm125125125
End hose lengthmm300030003000
Chassis modelmmZZ5347V524HE1ZZ5356V524ME1QL5420THBW2TDHY
Wheelbase4800+14004650+14001850+4575+1370
Engine typemmMC11.40-50MC11.40-506WG1-TCG51
Engine power297kw297kw338kw
Oil tank cubagekW400400400
Overall dimensions12295x2550x400012230x2550x400014040x2500x4000
Oil tank volume600600800
Control modeLManual+remote controlManual+remote controlManual+remote control
Maximum water pressure770.8
Pipe cleaning modeLWater cleaning/dry cleaningWater cleaning/dry cleaningWater cleaning/dry cleaning

We can also supply users all types of boom pumps for sale Australia, which are suitable for high building construction. We have 24m, 25m, 37m, 42m and 48m for your selection.

In addition concrete pump truck Australia, concrete line pumps for sale Australia, trailer concrete pumps for sale Australia, we also have concrete mixer with pump,mini concrete pumps for sale Australia for your choice, anyway, we will try our best to meet your demands. Last but not least, why you will get best price for line concrete pumps for sale Australia? Because we are going to establish oversea office in Australia, in addition, we have established oversea office in Uzbekistan, Pakistan, Philippines and Sri Lanka, etc, it is will be more and more convenient for you to buy from us!

Other Hot Sale Products

ABJZ40C diesel concrete pump mixer
ABJZ40C diesel concrete pump mixer


Items: ABJZ40C
Max. theo. concrete output(L./H)(M3/h): 40
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.45
Max.concrete pumping pressure(H./L.)(MPa): 10
Distribution valve type: S Valve
Winding motor power(KW): Hydraulic motor
Stir the motor power(KW): Hydraulic motor
Water pump motor power(KW): Hydraulic motor


ABJZ30C diesel cement mixer pump
ABJZ30C diesel cement mixer pump


Items: ABJZ30C
Max. theo. concrete output(L./H)(M3/h): 30
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.35
Max.concrete pumping pressure(H./L.)(MPa): 10
Distribution valve type: S Valve
Winding motor power(KW): Hydraulic motor
Stir the motor power(KW): Hydraulic motor
Water pump motor power(KW): Hydraulic motor


ABJS40D compulsory concrete mixer pump
ABJS40D compulsory concrete mixer pump


Items: ABJS40D
Max. theo. concrete output(L./H)(M3/h): 40
Concrete mixer model: JS750
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.75
Max.concrete pumping pressure(H./L.)(MPa): 8
Distribution valve type: S Valve
Winding motor power(KW): 7.5
Stir the motor power(KW): 30
Water pump motor power(KW): 0.75


ABJZ30D electric concrete mixer pump
ABJZ30D electric concrete mixer pump


Items: ABJZ30D
Max. theo. concrete output(L./H)(M3/h): 30
Mixer rated feed capacity(m3): 0.56
Mixer rated discharge capacity(m3): 0.35
Max.concrete pumping pressure(H./L.)(MPa): 10
Distribution valve type: S Valve
Winding motor power(KW): 5.5
Stir the motor power(KW): 4.5
Water pump motor power(KW): 0.55
