JBS40-JZC350

Electric Concrete Pump

Electric Concrete Mixing Pump-Concrete Drum Mixer With Pump

Concrete drum with mixer pump is with JZC series concrete drum mixer, therefore, if you need a large quantity of concrete, this type mixer pump will be your ideal choice, it can work constantly. We mainly have JBS30-JZC350 and JBS40-JZC350 concrete drum mixer with pump, i has characteristics of high efficiency, besides, different types have different output, you can see the specifications in detail, then choose a proper machine for your construction.

JZB200-10
JZB10-JZC200 electric mixer pump

Model: JZB10-JZC200
Max. theo. concrete output: 10m3/h
Hopper capacity: 400L
Motor Power: 18.5kw
Max.concrete pumping pressure: 10Mpa
Total weight: 3200kg
Max. Aggregate Diameter: Scree: 20mm

JBS30-JZC350 Electric Concrete Pump With Mixer

JBS30-JZC350 electric concrete pump with mixer
Model JBS30-JZC350
Max. Theoretical Conveying Capacity 30m3/h
Motor Power 47.55KW
Max Aggregate Size 30mm
Max Horizontal Conveying Distance 500m
Max Vertical Conveying Distance 120m
Distribution valve type S Valve
JBS30

JBS40-JZC350 Electric Concrete Mixing Pump

JBS40-JZC350
Model JBS40-JS500
Max Theoretical Conveying Capacity 40m3/h
Max Exit Pressure 11Mpa
Motor Power 70.1KW
Max Aggregate Size 40mm
Max Horizontal Conveying Distance 600m
Max Vertical Conveying Distance 150m
Mixer Model JS500
JBS40-JZC350 electric concrete mixinig pump

Electric Concrete Pump With Mixer-Compulaory Concrete Mixer And Pump

Compulsory electric concrete mixer with pump is with JS series twin shaft concrete mixer, therefore, it can produce high-quality concrete. What’s more, we have JB40-JS500 and JB40-JS750 for your selection, productivity is different, you can choose a right one according to your construction needs.

JBS40-JS series compulsory electric concrete pump with mixer

JBS40-JS500
JBS40-JS500

Model: JBS40-JS500
Max Theoretical Conveying Capacity: 40m3/h
Max Exit Pressure: 11Mpa
Motor Power: 70.1KW
Max Aggregate Size: 40mm
Max Horizontal Conveying Distance: 600m
Max Vertical Conveying Distance: 150m
Mixer Model: JS500

Model: JBS40-JS750
Max. Theoretical Conveying Capacity: 40m3/h
Motor Power: 83.6kw
Max Aggregate Size: 40mm
Max Horizontal Conveying Distance: 600m
Max Vertical Conveying Distance: 150m
Mixer Model: JS750

JB40-JS750 electric concrete mixinig pumps
JB40-JS750 electric concrete mixinig pumps

Specifications of electric mixer pump:

Items Units Parameters
JZB200-10
Whole performance of machine Max. theo. concrete output m3/h 10
Max.concrete pumping pressure MPa 10
Distribution valve type
Concrete cylinder diameter×stroke mm Ф140×1000
Hopper capacity L 400
Outlet diameter mm Ф100
Power system Main motor    kw
18.5
Vice motor kw 11
Kw 3
Water pump motor powe kw 0.55
Rotate speed r/min 1480
Feeding capacity L 0.25
Discharging capacity L 0.2
Hydraulic system Circuit type Open circuit
Pumping system pressure MPa 28
Mixing system pressure MPa
Capacity of oil tank L 370
The biggest transportation is away from vertically (/Level) m 100/300
Other parameters Max. aggregate diameter mm Diameter: 20
Inside diameter of delivering pipe mm Ф80
Dimensions:length×width×height mm 4200x2300x3150
Total weight kg 3200
Items Unit JBS30-JZC350 JBS40-JZC350 JBS40-JS500 JBS40-JS750
Max Theoretical Conveying Capacity m3/h 30 40 40 40
Max Exit Pressure Mpa 10 11 11 11
Concrete Cylinder bore * stroke mm Ф140×1000 Φ160×1200 Φ160×1200 Φ160×1200
Hydraulic Oil Tank Volume L 370 370 370 370
Exit Diameter mm Ф100 Φ150 Φ150 Φ150
Conveying Pipe Inner Diameter mm Ф100 Φ125/150 Φ125/150 Φ125/150
Motor Power KW 47.55 55.75 70.1 83.6
Max Aggregate Size mm 30 40 40 40
Max Horizontal Conveying Distance M 500 600 600 600
Max Vertical Conveying Distance M 120 150 150 150
Mixer Model JZC350 JZC350 JS500 JS750
Input Volume L 560 560 750 1200
Output Volume L 350 350 500 750
Mixer productivity M3/h 12-15 12-15 25 35
Drum Diameter Mm 1440 1440
Drum Rotary Speed (without load) rpm 18 18
Outline Dimension (L*W*H) mm 4200x2300x2600 4200x2300x2600 5100*2250*2860 5200*2250*3110
Weight Kg 4200 4500 5500 6500

Successful Cases of Our electric concrete mixinig pumps

Electric Concrete Mixer And Pump Bangladesh Was Finished Production And Test Run

Congratulations! Aimix group JBS40 electric concrete mixer and pump was finished installation and test run, it is going to be ...
Read More
electric concrete pump with mixer

JBS30-JZC350 Electric Concrete Mixer Pump Was Exported To Congo

Model: JBS30-JZC350 Max. Theoretical Conveying Capacity: 30m3/h Motor Power: 47.55KW Max Aggregate Size: 30mm Max Horizontal Conveying Distance: 500m Max ...
Read More
electrical concrete pump

Our JBS40-JS750 Concrete Mixer Pump Is Being Delivered To Indonesia

Model: JBS40-JS750 Max. Theoretical Conveying Capacity: 40m3/h Motor Power: 83.6kw Max Aggregate Size: 40mm Max Horizontal Conveying Distance: 600m Max ...
Read More
AIMIX JBS40 Electric Concrete Mixer Pump is Sold to Pakistan

We AIMIX Export Our JBS40 Electric Concrete Mixer with Pump to Pakistan Today

Today, we AIMIX export our JBS40 electric concrete mixer with pump to Pakistan. After some consultation and comparison, our Pakistan's users ...
Read More
AIMIX JBS30 Electric Concrete Mixer with Pump for Sale

AIMIX JBS30 Electric Concrete Mixer and Pump was Sold to Paraguay with High Reputation

Items Unit JBS30-JZC350 Max Theoretical Conveying Capacity m3/h 30 Max Exit Pressure Mpa 10 Concrete Cylinder bore * stroke mm Ф140×1000 Hydraulic Oil Tank Volume L 370 Exit Diameter mm Ф100 Conveying Pipe Inner Diameter mm ...
Read More

JBS40 Electric Concrete Mixer And Pump Was Ready To Bangladesh

Electric Concrete Trailer Pump

BS20D
BS20D
Item BS20D
Max. Theoretical Throughput(m3/h) 20
Max. Pumping Pressure(MPa) 10
Max.Vertical Conveying Distance(m) 140
Max.Horizontal Conveying Distance(m) 500
Max. Aggregate Diameter(mm) 20
Conveying Pipe Radius(mm) 100
Conveying Cylinder Bore X Piston Stroke(mm) 140*1000
Hydraulic Oil Tank Capacity(L) 240
Feeding Height(mm) 1100
Hopper Capacity(m3) 0.35
Power(kw) 37
BS30D
BS30D
Item BS30D
Max. Theoretical Throughput(m3/h) 30
Max. Pumping Pressure(MPa) 11
Max.Vertical Conveying Distance(m) 150
Max.Horizontal Conveying Distance(m) 600
Max. Aggregate Diameter(mm) 20/30
Conveying Pipe Radius(mm) 100
Conveying Cylinder Bore X Piston Stroke(mm) 160*1200
Hydraulic Oil Tank Capacity(L) 370
Feeding Height(mm) 1100
Hopper Capacity(m3) 0.4
Power(kw) 45
BS40D
HBT40
Item HBT-40
Max. Theoretical Throughput(m3/h) 40
Max. Pumping Pressure(MPa) 11 or 13
Max.Vertical Conveying Distance(m) 150
Max.Horizontal Conveying Distance(m) 600
Max. Aggregate Diameter(mm) 30/40
Conveying Pipe Radius(mm) 125
Conveying Cylinder Bore X Piston Stroke(mm) 180*1200
Hydraulic Oil Tank Capacity(L) 370
Feeding Height(mm) 1100
Hopper Capacity(m3) 0.6
Power(kw) 45/56

Item HBT-50
Max. Theoretical Throughput(m3/h) 50
Max. Pumping Pressure(MPa) 12 or 13
Max.Vertical Conveying Distance(m) 150
Max.Horizontal Conveying Distance(m) 600
Max. Aggregate Diameter(mm) 40/50
Conveying Pipe Radius(mm) 125/150
Conveying Cylinder Bore X Piston Stroke(mm) 180*1300
Hydraulic Oil Tank Capacity(L) 370
Feeding Height(mm) 1400
Hopper Capacity(m3) 0.68
Power(kw) 75

Item HBT-60
Max. Theoretical Throughput(m3/h) 60
Max. Pumping Pressure(MPa) 13/15/16
Max.Vertical Conveying Distance(m) 190
Max.Horizontal Conveying Distance(m) 800
Max. Aggregate Diameter(mm) 50
Conveying Pipe Radius(mm) 150
Conveying Cylinder Bore X Piston Stroke(mm) 200*1650
Hydraulic Oil Tank Capacity(L) 580
Feeding Height(mm) 1420
Hopper Capacity(m3) 0.68
Power(kw) 90

Item HBT-80
Max. Theoretical Throughput(m3/h) 80
Max. Pumping Pressure(MPa) 16
Max.Vertical Conveying Distance(m) 200
Max.Horizontal Conveying Distance(m) 1000
Max. Aggregate Diameter(mm) 50
Conveying Pipe Radius(mm) 150
Conveying Cylinder Bore X Piston Stroke(mm) 200*1800
Hydraulic Oil Tank Capacity(L) 580
Feeding Height(mm) 1420
Hopper Capacity(m3) 0.68
Power(kw) 110

Our HBT Series electric concrete pump is applicable on fine stone concrete conveying, floor heating construction, tunnel and underground construction, mortar conveying, used as spray pump when installed with incidental spraying equipment, for concrete, mortar, refractory material and green soil spraying, applied for high-rise conveying, railway, tunnel, bridge construction and special applications, hydraulic power, mining and national defense. Compared with diesel concrete mixer with pump, and our electric concrete pumps have strong power system, reliable hydraulic system, efficient pumping system and excellent electrical control system, which fully meet the modern construction requirements of high efficiency and low consumption. And we also advice you invest an electric concrete pump with mixer, it is with electric motor, as long as construction site has enough electricity, this machine will achieve constant function, our hot types are: JBS10-JZC200, JBS30-JZC350, JBS40-JZC350 and JBS40-JS750.

Specifications of electric concrete pump

Item HBT-20 HBT-30 HBT-40
Max. Theoretical  Throughput(m3/h) 20 30 40
Max. Pumping Pressure(MPa) 10 11 11/13
Max.Theoretical Vertical Conveying Distance(m) 140 150 150
Max.Theoretical Horizontal Conveying Distance(m) 500 600 600
Max. Aggregate Diameter(mm) 20 20/30 30/40
Conveying Pipe Radius(mm) 100 100 125
Conveying Cylinder Bore X Piston Stroke(mm) Φ140×1000 Φ160×1200 Φ180×1200
Hydraulic Oil Tank Capacity(L) 240 370 370
Feeding Height(mm) 1100 1100 1100
Hopper Capacity(m3) 0.35 0.4 0.6
Power(kw) 37 45 45/56
Dimension(Length×Width×Height)(mm) 4000×1350×1550 4500×1750×1600 4600×1850×1770

Features and Advantages of Our Electric Concrete Pump for Sale

Reliable performance: our electric concrete pump adopts Italy hydraulic drive, which reduce reversing impact. S values system is easy for maintaining as trailer pump for sale.

Complete machine of our electric concrete pump can be taken apart into two, which is easy to transport and install in mining construction location.

Core parts of our electric concrete pump are Japanese Kawasaki original, this equipment has long lifetime and reliable quality.

Our electric concrete pump adopts automatic lubrication system to ensure that equipment for a long time continuous operation.

Our electric concrete pump mixer has the electric list of spare parts to ensure a easy replacement, and it also has high accuracy and stability.

Specifications of electric concrete pump

Item HBT-50 HBT-60 HBT-80 HBT-90
Max. Theoretical  Throughput(m3/h) 50 60 80 90
Max. Pumping Pressure(MPa) 12/13 13/15/16 16 16/18
Max.Theoretical Vertical Conveying Distance(m) 150 190 200 220
Max.Theoretical Horizontal Conveying Distance(m) 600 800 1000 1200
Max. Aggregate Diameter(mm) 40/50 50 50 50
Conveying Pipe Radius(mm) 125/150 150 150 150
Conveying Cylinder Bore X Piston Stroke(mm) Φ180×1300 Φ200×1650 Φ200×1800 Φ200×1850
Hydraulic Oil Tank Capacity(L) 370 580 580 580
Feeding Height(mm) 1400 1420 1420 1420
Hopper Capacity(m3) 0.68 0.68 0.68 0.8
Power(kw) 75 90 110 110
Dimension(Length×Width×Height)(mm) 5200×2000×2260 6000×2160×2600 6300×2100×2250 6300×2100×2250

You Give Us a Chance, We Return You a Best Electric Concrete Pump

We Aimix Group is a manufacturer among many electric concrete pump manufacturers in China. We Aimix Group have got certificate of ISO9001:2000 and CE. We Aimix Group have been a verified supplier by BV and Alibaba.

We Aimix Group will try our best to ensure our uses to enjoy harmful, comfortable and quick service. The project Location of we Aimix Group is to explore our work around the Globe.

We Aimix Group pays more attention to details of our Electric Concrete Pump and other products, we hope that each product can reach the perfect embodiment. The products of we Aimix Group are granted “Henan famous brand” than other electric concrete pump suppliers.

We Aimix Group are really happy to provide you with a full ranges of industry-related consulting for our electric concrete pump, concrete batching plant, tower crane, construction lift, block making machine, stabilized soil plant and other products.
