Stationary Concrete Plant

The stationary concrete plant is fixed on the foundation and won’t be moved to another site. So it has a solid base and compact configuration, meanwhile, can realize higher production than mobile concrete plant. Therefore, stationary concrete batching plants are very suitable for the project with a long period and amount of work. For example, building construction, water conservancy engineering, bridge, and airport project, etc. Now let’s learn about how many capacities for your choice.

  • AJ-25 stationary concrete plant Pakistan
  • AJ-35 stationary concrete batching plant Philippines
  • AJ-50 stationary concrete batching plant Tajikistan
  • AJ-90 stationary concrete plant Uzbekistan
  • AJ-25 stationary concrete plant Pakistan
  • AJ-35 stationary concrete batching plant Philippines
  • AJ-50 stationary concrete batching plant Tajikistan
  • AJ-90 stationary concrete plant Uzbekistan

Types of stationary concrete plants

In addition capacity, there is another way to define the stationary concrete batch plant: the delivery of aggregate.

Skip hoist concrete batching plant

AJ-25, AJ-35, AJ-50, and AJ-75 are hopper type stationary concrete plants. This type of concrete mixing equipment has features of small land occupation, quick installation, convenient maintenance, etc. But its productivity is lower than belt types.

AJ-25 in Pakistan

AJ-25 stationary batching plant in Pakistan

Model AJ-25
Theoretical Productivity (m3/h) 25
Mixer Model (Mixer Output L) JS500
Mixer Power (kW) 18.5
Mixing Cycle Period (s) 67
Rated Input Volume (Model of Batching Machine L) 800
Standard Aggregate Bin Capacity (m3) 3×3
Category of Aggregate 2/3
Overall Weight (ton) ≈15
Installation Power (kW) ≈65


AJ-35 in Philippines

AJ-35 stationary concrete batching plant in Philippines

Model AJ-35
Theoretical Productivity (m3/h) 35
Mixer Model (Mixer Output L) JS750
Mixer Power (kW) 30
Mixing Cycle Period (s) 72
Rated Input Volume (Model of Batching Machine L) 1200
Standard Aggregate Bin Capacity (m3) 3×5
Category of Aggregate 2/3/4
Overall Weight (ton) ≈18
Installation Power (kW) ≈75


AJ-50 in Philippines

AJ-50 stationary concretebatching plant in Philippines

Model AJ-50
Theoretical Productivity (m3/h) 50
Mixer Model (Mixer Output L) JS1000
Mixer Power (kW) 2×18.5
Mixing Cycle Period (s) 72
Rated Input Volume (Model of Batching Machine L) 1600
Standard Aggregate Bin Capacity (m3) 3×8
Category of Aggregate 3/4
Overall Weight (ton) ≈23
Installation Power (kW) ≈100


AJ-75 in Uzbekistan

AJ-75 stationary concrete plant Uzbekistan

Model AJ-75
Theoretical Productivity (m3/h) 75
Mixer Model (Mixer Output L) JS1500
Mixer Power (kW) 2×30
Mixing Cycle Period (s) 72
Rated Input Volume (Model of Batching Machine L) 2400
Standard Aggregate Bin Capacity (m3) 3×12
Category of Aggregate 4/5
Overall Weight (ton) ≈30
Installation Power (kW) ≈140


Belt conveyor type concrete plant

Why is it named belt type plant? Because all of aggregate will enter mixer through a long belt. This type stationary concrete batching plant for sale has characteristics of accurate weighing, efficient production and completely discharge. So if you want to produce a large quantity of quality concrete, this type will be your best choice. Models mainly are: AJ-60, AJ-90, AJ-120 and AJ-180. If you don’t wanna these types, we can customize a suitable one for you.

AJ-60 in Sri Lanka

AJ-60 stationary batching plant in Sri Lanka

Model AJ-60
Theoretical Productivity (m3/h) 60
Mixer Model (Mixer Output L) JS1000
Mixer Power (kW) 2×18.5
Mixing Cycle Period (s) 60
Rated Input Volume (Model of Batching Machine L) 1600
Standard Aggregate Bin Capacity (m3) 4×7
Category of Aggregate 4/5
Overall Weight (ton) ≈40
Installation Power (kW) ≈110

AJ-90 in Uzbekistan

AJ-90 stationary concrete plant in Uzbekistan

Model AJ-90
Theoretical Productivity (m3/h) 90
Mixer Model (Mixer Output L) JS1500
Mixer Power (kW) 2×30
Mixing Cycle Period (s) 60
Rated Input Volume (Model of Batching Machine L) 2400
Standard Aggregate Bin Capacity (m3) 4×15
Category of Aggregate 4/5
Overall Weight (ton) ≈68
Installation Power (kW) ≈160


AJ-120 stationary concrete batching plant
AJ-120 stationary concrete batching plant
Model AJ-120
Theoretical Productivity (m3/h) 120
Mixer Model (Mixer Output L) MAO3000/2000(SICOMA)
Mixer Power (kW) 2×37
Mixing Cycle Period (s) 65
Rated Input Volume (Model of Batching Machine L) 3000
Standard Aggregate Bin Capacity (m3) 4×15
Category of Aggregate 4/5/6
Overall Weight (ton) ≈93
Installation Power (kW) ≈220


AJ-180 stationary concrete batching plant
AJ-180 stationary concrete batching plant
Model AJ-180
Theoretical Productivity (m3/h) 180
Mixer Model (Mixer Output L) MAO4500/3000(SICOMA)
Mixer Power (kW) 2×55
Mixing Cycle Period (s) 65
Rated Input Volume (Model of Batching Machine L) 4500
Standard Aggregate Bin Capacity (m3) 4×20
Category of Aggregate 4/5/6
Overall Weight (ton) ≈101
Installation Power (kW) ≈290



In a word, you can choose a most suitable plant for your project. Now you have known the capacity of stationary concretebatching plant we can supply, next we will learn about the structure of the concrete mixing equipment, so that you will know what raw materials you need and how many labors you need.

Feedback from our users

AJ-50 user spoke highly of our plant

Customer Feedback From AJ-35 Hopper Concrete Batching Plant Operator In Philippines

Structure of stationary concrete plant

Raw materials storage system

For aggregate batching machine: we use wheel loader to discharge raw materials into aggregate batcher, through aggregate batcher, raw materials, such as, pebble, macadam, sand will be batched accurately,Our batching machine has 3 types to choose from:Central weighing batcher;Belt weighing batcher;Individual weighing batcher.

Central weighing batcher
Central weighing batcher

Belt weighing batcher
Belt weighing batcher

Individual weighing batcher
Individual weighing batcher



For powder cement silo: AIMIX has four types of powder storage system: welded type cement silo, bolted type cement silo, low level horizontal cement silo and mobile cement silo. Welded type is a complete unit with lower price; bolted type will cost very little in shipment; horizontal type is low-level; while mobile type is convenient to move around.
welded type cement silo
welded type cement silo
horizontal cement silo
horizontal cement silo
bolted type cement silo
bolted type cement silo


For water and additive. At the installation time, our engineer will build a reservoir. And additive is in its pump.

Mixing machine

According to the different mixing effect, you can choose JS series twin shaft mixer, Sicoma concrete mixer, JN series planetary concrete mixer. Usually we use JS series concrete mixer.

JS500 twin shaft mixer
JS500 twin shaft mixer
sicoma concrete mixer
sicoma concrete mixer
JN750 planetary cement mixer
JN750 planetary cement mixer

Specifications of JS series concrete mixer

Item Charging Capacity (L) Discharging Capacity(L) Productivity( m/h) Aggregate Size(cobble/gravel) (mm) Overall Dimension
(LXWXH) (mm)
JS500 800 500 25 Min 80/60 4486x3030x5280
JS750 1200 750 35 Min 80/60 5100x2250x6700
JS1000 1600 1000 50 Min 80/60 8765x3436x9540
JS1500 2400 1500 75 Min 80/60 9645X3436X9700
JS2000 3200 2000 100 Min 80/60 3500X2320X1677
JS3000 4800 3000 150 Min 80/60 3990X2600X1700
JS4000 6400 4000 200 Min 120/100 4450X3050X2380

Materials transport system

For aggregate: we use belt conveyor or bucket. They can realize different productivity. AJ-25, AJ-35, AJ-50 and AJ-75 are using bucket; AJ-60, AJ-90, AJ-120 and AJ-180 stationary batching plants use belt conveyor. So belt conveyor type concrete plant is much more efficient than bucket type.

use hopper
use hopper
use belt conveyor
use belt conveyor

Control system

There are two types control system you can choose: semi automatic and fully automatic. The only difference is whether it is with computer. Fully automatic can print some details, and visually display the working state of the stationary concrete batching plant and formula proportion.

control panel
control room
control room of concrete plant

In addition these systems, there are also weighing system, aggregate weighing system is aggregate batcher, while for powder and liquid, they have their own weighing system at the top of concrete mixer machine. Now it is time to know the whole concrete production procedure, you will know how does a stationary concrete mixing plant for sale work.

Installation about stationary concrete plants

Take skip hoist concrete plant as an example.

1. Assemble main mixer and weighing system. Main engine should be in the middle of the foundation.

2. Hoist the cement silo. If you choose bolted type cement silo, you need to assemble the silo in advance.

3. Assemble concrete batching machine. It will take three to four hours to finish this step.

4. According to the drawing, put the control room in right position.

5. Assemble other parts of the main mixer.

6. Add the oil and debug.

7. Train the local operator and produce concrete.

Installation Video Of AJ-35 Concrete Batching Plant


All in all, the normal installation time of skip hoist concrete batching plant is about 10 days, you need to pay attention.

Working procedure of stationary concrete batch plant

In general, there are five steps for equipment to produce concrete: loading, transport, weighing, mixing, and unloading.

Loading:

wheel loader loads the raw materials into the aggregate batching machine. After weighing, then transport to mixing system.

Water pump and additive pump pour the water and additive into weighing system, then enter mixing system.

Cement and fly ash will enter their own weighing system through a screw conveyor, then enter the concrete mixer machine.

Mixing:

After all above steps, three kinds of raw materials are in twin shaft concrete mixer, the core of stationary concrete batch plant for sale.

Unloading:

When the set mixing time is over, the finished products will be unloaded into a concrete transport truck and sent to the site. If you need an on-site concrete batching plant, you may don’t need a concrete transit mixer.

The above is the whole concrete production process and also the workflow of stationary concrete mixing plant. There are many details that need to be paid attention to. If you buy our machines, our staff will show you some routine repairs and maintenance.

How about stationary concretebatching plant price

Now you must be very curious about stationary concrete batching plant price. But we can’t display the price on this page, for our customers are from all over the world, because of different models, different configurations, and different transportation, the costs Prices will be inconsistent.Thus, if you want to get an accurate price, leave your contact information on this page, our salesman will make a corresponding quotation for you. At the end of this page, I want to show you some installation details, you can have a look, hope it is useful for you.

AJ50 Skip hoist type concrete plant in Philippines
AJ50 Skip hoist type concrete plant in Philippines

AJ50 Skip hoist type concrete plant in Philippines
AJ50 Skip hoist type concrete plant in Philippines

Through this page, I believe you have been very clear about a stationary concrete plant, you may know which type is your ideal choice. So if you have any other questions, contact us, we will give you a quick reply.
