Wide application
Concrete batching plant Australia is often used in such constructions with large work quantity, long construction period, large and medium-sized water conservancy engineering, electric power project, hourse building, airport project, and bridge construction. If you want to do other types of the concrete business in Australia, contact us, we will also give you useful advice.
Free consultance, and free quotation.
Types of batching plant concrete equipments for sale in Australia
Besides, I need to mention, types of concrete batching plants for sale in Australia can bedivided into two types: skip hoist concrete plant in Australia and belt conveyor type batch plant for sale Australia. AJ-25, AJ-35, AJ-50 and AJ-75 are skip hoist type, while AJ-60, AJ-90, AJ-120, AJ-180 are belt conveyor type. Let’s distinguish between these two concrete plant in australia.
Skip hoist type
AJ-25 in PakistanCapacity: 25(m3/h)
- Theoretical Productivity (m³/h):50
- Mixer Discharging Volume (L):500
- Mixer Feeding Volume (L):800
- Mixer Motor Power (kW):18.5
- Discharging Height (m):3.8
- Aggregate Material Quantity (m3):3×3
- Cycle Period (s):72
- Max. Aggregate Size (mm):80/60
AJ-35 in the UzbekistanCapacity: 35(m3/h)
- Mixer Discharging Volume (L)750
- Mixer Feeding Volume (L):1200
- Mixer Motor Power (kW):30
- Discharging Height (m):4.1
- Aggregate Material Quantity (m3):5×3
- Max. Aggregate Size (mm):80/60
AJ-50 in Sri LankaCapacity: 50(m3/h)
- Mixer Model (Mixer Output L):750
- Mixer Power (kW):2×18.5
- Mixer Motor Power (kW):30
- Rated Input Volume(L):1600
- Category of Aggregate:3/4
- Installation Power (kW):≈100
Specifications of hopper type
Model | Bucket type | |||
AJ-25 | AJ-35 | AJ-50 | AJ-75 | |
Theoretical Productivity (m³/h) | 25 | 35 | 50 | 75 |
Mixer Model (Mixer Output L) | JS500 | JS750 | JS1000 | JS1500 |
Mixer Power (kW) | 18.5 | 30 | 2×18.5 | 2×30 |
Mixing Cycle Period (s) | 72 | 72 | 72 | 72 |
Max.Aggregate Size (mm) | Φ60 | Φ60 | Φ60 | Φ80 |
Standard Aggregate Bin Capacity (m³) | 3×3 | 3×5 | 3×8 | 3×12 |
Kind of Aggregate | 2/3/4 | 2/3/4 | 2/3/4 | 2/3/4 |
Max. Discharging Height (m) | 3.8 | 4.1 | 4.1 | 4.1 |
Overall Weight (ton) | ≈15 | ≈18 | ≈23 | ≈30 |
Installation Power (kW) | ≈65 | ≈75 | ≈100 | ≈140 |
Power Supply | 380V/220V/415/440V, 50/60HZ, 3Phase |
Belt conveyor type
AJ-60 in the PhilippinesCapacity: 60(m3/h)
- Mixer Discharging Volume (L):1000
- Mixer Feeding Volume (L):1600
- Mixer Motor Power (kW):18.5×2
- Discharging Height (m):4.1
- Aggregate Material Quantity (m3):7×4
- Cycle Period (s):60
- Max. Aggregate Size (mm):80/60
- Cement Silo (t) (optional):2×100
AJ-90 in UzbekistanCapacity: 90(m3/h)
- Mixer Discharging Volume (L)1500
- Mixer Feeding Volume (L): 2400
- Mixer Motor Power (kW): 30×2
- Discharging Height (m): 4.1
- Aggregate Material Quantity (m3): 15×4
- Cement Silo (t) (optional): 3×100
c
Specifications of belt type
Model | Belt type | |||
AJ-60 | AJ-90 | AJ-120 | AJ-180 | |
Theoretical Productivity (m³/h) | 60 | 90 | 120 | 180 |
Mixer Model (Mixer Output L) | JS1000 | JS1500 | MAO3000/2000(SICOMA) | MAO4500/3000(SICOMA) |
Mixer Power (kW) | 2×18.5 | 2×30 | 2×37 | 2×55 |
Mixing Cycle Period (s) | 60 | 60 | 65 | 65 |
Max.Aggregate Size (mm) | Φ60 | Φ80 | Φ80 | Φ80 |
Standard Aggregate Bin Capacity (m³) | 4×7 | 4×15 | 4×15 | 4×20 |
Kind of Aggregate | 2/3/4 | 2/3/4 | 2/3/4 | 2/3/4 |
Max. Discharging Height (m) | 4.1 | 4.1 | 4.3 | 4.3 |
Overall Weight (ton) | ≈40 | ≈68 | ≈93 | ≈101 |
Installation Power (kW) | ≈110 | ≈160 | ≈220 | ≈290 |
How to select suitable component
For cement silos
It all depends on your project condition. In addition to cement silos are unfixed, other components should be matched perfectly. You can choose any size of cement storage silo for your project. Both small and big are ok. If you need a large quantity of ready mix concrete available, you’d better prepare a big silo.
For screw conveyor
You can decide the number of screw conveyors according to the type of cement bin you choose.
For concrete mixing machine
Generally, we use JS series twin shaft concrete mixers as the mixing engine in the concrete batching plants, you can choose other types, such as planetary concrete mixer, JSS double spiral twin shaft mixer, pan mixer, concrete drum mixer, etc, they can produce concrete mixture of different quality.
Ways to find reliable concrete batching plant manufacturers in Australia
There are three points of concrete batch plants for sale in australia you need to pay much more attention: product quality, product price and after-sales service. If you want to do concrete plant business for sale in Australia, the first thing you need to do is looking for several reputable manufacturers. So how to judge their reputation? Here are some tips:
- 1. Visit their factory and office. A big factory and office mean they have large orders and strong comprehensive strength.
- 2. The professional degree of engineers. Professional engineer will install perfect concrete plant, which will be convenient for you to maintain. Also, save your money.
- 3. Check their after-sales cases. A large number of cases display their export strength and reputation.
After-sales cases
AJY-35 was installed
The Installation Of AJ-50
AJ-90 was exported
Feedback from AJY-35
AJ-50 installation
AJ-60 debug
Install AJY-60 in the Philippines
Install AJ-50 in Pakistan
Install AJY-35 in Uzbekistan
Install AJ-50 in the Philippines
Characteristics of skip hoist concrete batching plant for sale Au
- 1. Simple structure;
- 2. Small footprint;
- 3. Low cost;
- 4. Convenient maintenance.
Features of belt conveyor concrete batching plant for sale in Australia
- 1. Fast feeding;
- 2. Long conveying distance;
- 3. High efficiency;
- 4. Low fault rate, can finish the mass operation demand;
- 5. Short production period;
- 6. Large discharge volume, suitable for commercial concrete plant.
Shipment of each component
For the convenience of transportation, when export concrete batching plant for sale Australia, its compositions, such as twin shaft concrete mixer, bottom rail, ladder, diagonal bracing, connecting angle, outrigger, foundation bolt, slouch are in bulk condition, other components are in whole.
Assemble notice
The whole assembly process should be safe and reliable, requirements are below:
When hoisting, the center of gravity of the machine shall not be offset. The steel wire rope shall be accurately hoisted on the circular hook of the tray. The hook on the mixing drum shall not be used for lifting the whole machine.
When loading, the upper track is folded and bound with iron wire, and the hopper is fixed by the brake pin;
The whole machine and parts should be firmly and stably fixed in the carriage and hooked securely.
AIMIX GROUP CO., LTD has over 30 years experience of in production, innovation, marketing, and sales of concrete batching plant business for sale Australia. Aimix is one of the best concrete batching plant manufacturers australia. Up to now, they have not only sold plants to more than 100 countries but also set up LBS centers in foreign countries, such as Pakistan, Uzbekistan, the Philippines, Sri Lanka, and Indonesia. Australia, one of the most important markets, we will establish an after-sales service center this year, we promise to give you best plant with best service and price!
